Piaggio Beverly 125

Piaggio scooter equip it with a 124 cc engine, 1-cylinder, 4-stroke, SOHC, liquid-cooled. Strength 15 hp and 12 Nm of torque. Beverly uses a CVT transmission. If the reference data from Italy, this machine has a standard EURO 3.

Specifications Beverly in Italy said front suspension Telescopic hydraulic fork with the adopted 35-mm stanchions - 90 mm wheel travel.

  Rear suspension Double hydraulic shock absorbers with adjustable preload with four settings - 81 mm wheel travel.

Brakes front / rear discs measuring 300 mm and 240 mm. Diameter alloy wheels 16 "fill in the front and 14" behind.

and to the specifications
under this

 Specification

Engine and transmission
Engine type : 1 cylinders, 4-stroke, Single
Displacement : 124 cc (7.58 cubic inches)
Bore × stroke : 57 mm × 49 mm (oversquare - shortstroke)
Cooling system : Water cooled
Power : 14.96 HP (11 kW) @ 9250 rpm
Torque : 12 Nm (1.22 kg-m) @ 7250 rpm
Throttle : Cable operate
Valves
Valve train : SOHC, non-variable
Valves per cylinder : 4
Fuel and ignition
  > Sparks per cylinder : 1
  > Fuel supply system : Fuel injection
  > Ignition type :  Digital CDIEngine mounting : Transverse
Lubrication system : Wet sump
Gear box :  Automatic
Clutch :  Dry, centrifugal clutch, cable operated
Final drive : Shaft
Starter : Electric

Dimensions
Physical measures
   > Length :     2150 mm
   > Width:     780 mm
Wheel base :     1535 mm
Seat height :     790 mm
Weight
   > Curb weight :     162 kg

Chassis and suspension
Frame type :  steel, Double cradle frame
Front
   > Suspension:     Cartridge
   > Suspension travel:     90 mm
Brake :     Single Disk, Ø300 mm
Tire :     110 / 70 R16 R
Rear
    > Suspension : twin shock, Swingarm
    > Suspension travel : 81 mm
    > Brake : Disk, Ø240 mm
    > Tire : 140 / 70 R14 R
Other
Power-to-weight ratio : 0.07 HP/kg    (14.73 kg/HP)
Fuel capacity : 12.5 l
Number of riders : 2 persons
